| Model | Color | Power Consumption (W) | Channels | Dimension |
|---|---|---|---|---|
| MDBB-LSRH100W | W | 30 | 1CH |  |
| MDBB-LSRH200W | W | 60 | 2CH | |
| MDBB-LSRH300W | W | 90 | 3CH | |
| MDBB-LSRH400W | W | 120 | 4CH | |
| MDBB-LSRH500W | W | 150 | 5CH | |
| MDBB-LSRH600W | W | 180 | 6CH | |
| MDBB-LSRH700W | W | 210 | 7CH | |
| MDBB-LSRH800W | W | 240 | 8CH | |
| MDBB-LSRH900W | W | 270 | 9CH | |
| MDBB-LSRH1000W | W | 300 | 10CH | |
| MDBB-LSRH1100W | W | 330 | 11CH |  |
| MDBB-LSRH1200W | W | 360 | 12CH | |
| MDBB-LSRH1300W | W | 390 | 13CH | |
| MDBB-LSRH1400W | W | 420 | 14CH | |
| MDBB-LSRH1500W | W | 450 | 15CH | |
| MDBB-LSRH1600W | W | 480 | 16CH | |
| MDBB-LSRH1700W | W | 510 | 17CH | |
| MDBB-LSRH1800W | W | 540 | 18CH | |
| MDBB-LSRH1900W | W | 570 | 19CH | |
| MDBB-LSRH2000W | W | 600 | 20CH | |
| MDBB-LSRH2100W | W | 630 | 21CH |  |
| MDBB-LSRH2200W | W | 660 | 22CH | |
| MDBB-LSRH2300W | W | 690 | 23CH | |
| MDBB-LSRH2400W | W | 720 | 24CH | |
| MDBB-LSRH2500W | W | 750 | 25CH | |
| MDBB-LSRH2600W | W | 780 | 26CH | |
| MDBB-LSRH2700W | W | 810 | 27CH | |
| MDBB-LSRH2800W | W | 840 | 28CH | |
| MDBB-LSRH2900W | W | 870 | 29CH | |
| MDBB-LSRH3000W | W | 900 | 30CH |
● Condenser lens MLBB- □ and diffusion plate MKBB-LSR □ (optional) can be attached. Replace the □ with its size, in 100mm units. Product line from 100 to 1800 mm.Please tell us whether you want a condenser lens or diffusion plate attached. Diffusion plates are 30%, 60%, 80% or 90%.
Powel Supply applicationPower Supply for MDBB-LSRH
| Model | MMC-300M10 -TP | MMC- 600M20 -TP | MMC-1000M30 -TP |
|---|---|---|---|
| Input Voltage | AC100〜240V | ||
| Operating frequency | 50 / 60Hz | ||
| Capacity | 30W/CH | ||
| Channels | 10CH | 20CH | 30CH |
| Dimming method | Method to vary output current | ||
| External control | LAN ON/OFF | ||
| External control cable |  |
||
| Size | 100 〜 1000 | 1100 〜 2000 | 2100 〜 3000 |
| Dimension |  |
 |
 |
