| Model | Color | Power Consumption (W) | WD | SAG* | Dimensions | ||
|---|---|---|---|---|---|---|---|
| MDR-32/10DR | DR | 1.6 | 20-35 | 6E |  |
||
| MDR-32/10□ | DW | B | G | 1.8 | 20-35 | FF | |
| MDR-38/15DR | DR | 1.8 | 20-35 | 6E |  |
||
| MDR-38/15□ | DW | B | G | 2.2 | 20-35 | FF | |
| MDR-40/25DR | DR | 1.2 | 25-45 | 6E |  |
||
| MDR-40/25□ | DW | B | G | 1.5 | 25-45 | FF | |
| MDR-42/18DR | DR | 2.2 | 25-45 | 6E |  |
||
| MDR-42/18□ | DW | B | G | 2.6 | 25-45 | FF | |
| MDR-50/25DR | DR | 3 | 30-50 | 6E |  |
||
| MDR-50/28□ | DW | B | G | 2.7 | 30-50 | FF | |
| MDR-66/36DR | DR | 4.3 | 40-70 | 70 |  |
||
| MDR-66/36□ | DW | B | G | 5.4 | 40-70 | FF | |
| MDR-70/39DR | DR | 4.9 | 20-60 | 71 |  |
||
| MDR-70/39□ | DW | B | G | 5.8 | 20-60 | FF | |
| MDR-90/50DR | DR | 7.1 | 40-90 | 73 |  |
||
| MDR-90/50□ | DW | B | G | 6.5 | 40-90 | FF | |
| MDR-110/60DR | DR | 9.6 | 35-90 | 75 |  |
||
| MDR-110/60□ | DW | B | G | 9.6 | 35-90 | FF | |
| MDR-140/95DR | DR | 13.9 | 50-110 | 78 |  |
||
| MDR-140/95□ | DW | B | G | 10.8 | 50-110 | FF | |
● DR=Red, DW = White, B = Blue, G= Green, in ☐.
● Can attach a diffusion plate and polarization plate (optional).
● Input voltage is DC12V, but we can also make DC24V products.
● We can also make other sizes.
● DC24V models have HV at end of the model number.
* SAG is the maximum voltage setting for a SAG power supply. See details here.
