Built-in co-axial illumination
Suitable for various applications, inspection of wafer, IC chip, etc...
| Model | Magnification | WD | Resolution | Object side NA | Depth of field | TV distortion | Maximum Compatible sensor |
Dimension |
|---|---|---|---|---|---|---|---|---|
| TLZ0220C (Manual Zoom) |
0.2x-2.0x | 227mm | 22.4μ〜 7.6μ |
0.015〜 0.044 |
13.1mm〜 0.45mm |
-0.16%〜 0.16% |
1/1.8” |  |
| TLZ0220C-SM (Motorized Zoom) |
 |
○Indicated specifications are design values. ○Resolution indicates a theoretical resolution at a wavelength of 550nm. ○Depth of field is calculated assuming permissible circle of confusion is 40μm.
